X-MS50223LM4070-3030HE-64
Square LED Modules
  • Default driving method is constant current input
  • This modul can be used 16 series x4 parallels or 8 series x 8 parallels options.
  • This module is compatible with Zhaga Standart Book 15.
  • CCT Range from 2000K up to 6500K
  • Luminous flux range from 2879 lm to 10261 lm
  • Efficacy of the module up to 181 lm/W
  • CRI 80 is standart, CRI 70 and CRI 90 are available
  • Outstanding system color tolerance MacAdam 3 over the full operating area
  • Simple installation (e.g. screw)
  • Long life-time > 60,000 hours
  • 5 years guarantee at specified conditions
Teklif Al
Dökümanlar
  • NFSW757GT-V3_R8000 İNDİR
    LED NFSW757GT-V3_R8000
    Correlated Color Temperature (CCT) 4000K
    Color Rendering Index (CRI) 80+
    Module Operating Voltage (V) 45,44 47,36 49,92
    Module Operating Current (mA) 350 500 700
    Branch Operating Current (mA) 88 125 175
    Module Power (W) 15,90 23,68 34,94
    Module Light Output (lm) 2.879 4.002 5.416
    Module Efficiency (lm/W) 181 159 155
    NF2W757GR-V3_R8000 İNDİR
    LED NF2W757GR-V3_R8000
    Correlated Color Temperature (CCT) 4000K
    Color Rendering Index (CRI) 80+
    Module Operating Voltage (V) 90,24 93,76 98,08
    Module Operating Current (mA) 350 500 700
    Branch Operating Current (mA) 88 125 175
    Module Power (W) 31,58 46.88 68,66
    Module Light Output (lm) 5.085 6.798 9.543
    Module Efficiency (lm/W) 161 145 139
    LUXEON 3030 2D Sq. İNDİR
    LED LUXEON 3030 2D Sq.
    Correlated Color Temperature (CCT) 4000K
    Color Rendering Index (CRI) 80+
    Module Operating Voltage (V) 92,32 95,36 99,04
    Module Operating Current (mA) 350 500 700
    Branch Operating Current (mA) 88 125 175
    Module Power (W) 32,31 47,68 69,33
    Module Light Output (lm) 5.622 7.724 10.261
    Module Efficiency (lm/W) 174 162 148
    LUXEON 3030 HE + İNDİR
    LED LUXEON 3030 HE +
    Correlated Color Temperature (CCT) 4000K
    Color Rendering Index (CRI) 70+
    Module Operating Voltage (V) 43,68 44,48 45,60
    Module Operating Current (mA) 350 500 700
    Branch Operating Current (mA) 88 125 175
    Module Power (W) 15,29 22,24 31,92
    Module Light Output (lm) 3.226 4.515 6.161
    Module Efficiency (lm/W) 211 203 193
  • PCB Bilgileri İNDİR
    Module Code X-MS50223LM4070-3030HE-64
    PCB Material ALU Electrical Connection
    Operating Temperature(°C) -40 ~ +85 Parallel 4
    Storage Temperaature(°C) -40 ~ +55 Series 16
    Thermal Conductivity(W/m-k) 1> LED Quantity 64
  • X-MS50223LM4070-3030HE-64 Datasheet İNDİR
