LVED SPD 20KV IP67 Class I
SURGE PROTECTION DEVICE (SPD)
  • Maximum continuous operating voltage (Uc): 320 VAC, 50/60 Hz
  • Nominal discharge current (In): 10 kA; maximum discharge current (Imax): 20 kA
  • Test classification: Class II (T2) / Class III (T3)
  • Suitable for Class I luminaires (IEC 60598)
  • Open-circuit voltage (Uoc): 20 kV; voltage protection level (Up): ≤ 1.8 kV
  • IP67; operating temperature: -40°C to +80°C
  • LED status indicator and 100,000 hours rated lifetime
Get Offer
Documents
  • LVED SPD 20KV IP67 Class I Datasheet DOWNLOAD
