X-ML29920LM-4080-2835xx-180
Linear LED Modules
  • Default driving method is constant current input
  • CCT Range from 2700K up to 6500K
  • This module is standard and can be connected as 90 Series 2 Parallel.
  • Luminous flux range from 1134 lm to 26093 lm
  • Efficacy of the module up to 205 lm/W
  • CRI 80 is standard
  • Outstanding system color tolerance MacAdam 3 over the full operating area
  • Simple installation (e.g. screw)
  • Long life-time > 60,000 hours
  • 5 years guarantee at specified conditions
Teklif Al
Dökümanlar
  • 2835 SA-A1 İNDİR
    LED 2835 SA-A1
    Correlated Color Temperature (CCT) 4000K
    Color Rendering Index (CRI) 80+
    Module Operating Voltage (V) 251 260
    Module Operating Current (mA) 240 350
    Branch Operating Current (mA) 120 175
    Module Power (W) 60,32 90,84
    Module Light Output (lm) 10.254 14.444
    Module Efficiency (lm/W) 170 159
    2835 SA-E1 İNDİR
    LED 2835 SA-E1
    Correlated Color Temperature (CCT) 4000K
    Color Rendering Index (CRI) 80+
    Module Operating Voltage (V) 245 251
    Module Operating Current (mA) 240 350
    Branch Operating Current (mA) 120 175
    Module Power (W) 58,79 87,96
    Module Light Output (lm) 11.347 16.008
    Module Efficiency (lm/W) 193 182
    2835 RA-2K1 İNDİR
    LED 2835 RA-2K1
    Correlated Color Temperature (CCT) 4000K
    Color Rendering Index (CRI) 80+
    Module Operating Voltage (V) 275 284
    Module Operating Current (mA) 240 350
    Branch Operating Current (mA) 120 175
    Module Power (W) 65,88 99,23
    Module Light Output (lm) 9.223 12.899
    Module Efficiency (lm/W) 140 130
  • PCB Bilgileri İNDİR
    Module Code X-ML29920LM-4080-2835xx-180
    PCB Material ALU Electrical Connection
    Operating Temperature(°C) -40 ~ +100 Parallel 2
    Storage Temperaature(°C) -40 ~ +55 Series 90
    Thermal Conductivity(W/m-k) 1> LED Quantity 180
  • X-ML29920LM-4080-2835xx-180 Datasheet İNDİR
  • Uygulamalar İNDİR
